Soft Avatars Overview

Soft Avatars Overview

Soft avatars are high quality avatars that are designed to mimic the behavior and shape shifts of the human body in different garments to achieve realistic presentation of garments. Soft avatar behavior considers the amount of pressure a garment applies on a certain part of the body as well as the level of softness of that specific body part, and gravity effects, then the shape of the body of the soft avatar changes accordingly.

The following table shows the available soft avatars:

Type Name Description Thumbnail



Young woman

Sofia soft avatar


Young woman

Olivia soft avatar



Young man

Oliver soft avatar



A new plus size avatar

Joseph soft avatar

Soft Avatars size chart

  Olivia Sofia Oliver Joseph
Height 173.1cm 167.7cm 181.1cm 182.2cm
Neck 35.8cm 40.1cm 40.9cm 46.9cm
Shoulders 37.8cm 40.7cm 44.8cm 53.8cm
Bust/Chest 88.9cm 118.4cm 101.5cm 124.5cm
Waist 68.9cm 101cm 86cm 116.5cm
Hip 95.2cm 127.3cm 99.5cm 122.5cm
Bicep 25.8cm 38.3cm 34cm 41.8cm
Thigh 55.4cm 72.1cm 57.3cm 69.9cm
Cup Size B D - -

Simulation of Soft Avatars

When a soft avatar is in use, the Dress button includes a Soft Avatar Simulation option. The Soft Avatar Simulation option allows the soft avatar body to change form according to gravity force without necessarily dressing a garment.

Soft avatar simulation

During simulation a pillow icon appears on the Dress button to indicate simulation of a soft avatar.

Dress soft avatar button

​Version 2023.2
​As the simulation is running, a progress bar appears at the bottom of the 3D window ​​progress-bar.png.The simulation will automatically stop when done.

Note that after an avatar body takes a new shape, whether dressed or not, it will keep the new shape while styling or applying changes to garments.

To load a non-deformed avatar, use the Prepare button or simply load a screenshot with a non-deformed avatar shape.

When simulation is done, a snapshot is generated.

Soft Snapshot

  • Soft avatar snapshots have a small pillow icon at the top of the thumbnail.

  • Soft avatar snapshots are named after the avatar and soft, for example Sofia_Soft.

  • When you load a soft avatar snapshot the Soft Avatar Simulation option in the Dress button is automatically enabled.

  • When you load a garment only soft avatar snapshot, the garment is loaded without an avatar but is loaded with its soft avatar deformations.

Editing a Soft Avatar's Body Softness

You can edit the avatar's body softness through the 3D Environment options from the Main menu, or by using right click.

To edit the body softness of the avatar:

  1. Right click on the avatar, then select Edit Avatar. The Edit Avatar options are displayed in the Context view.

    Or select 3D Environment in the Main menu, then Edit Avatar. The Edit Avatar options are displayed in the Context view.

  2. Select Body Softness. The body softness options are displayed.

    Edit avatar options

  3. Select the desired body softness level.

Deformation Map

The deformation map​ is a feature that shows the level of deformation each soft avatar body part has gone through as a result of garment pressure.
The level of soft body part deformation is presented in colors. Red indicates the highest level of deformation, blue indicates the lowest level of deformation.
To access the deformation map:
  1. On the Main menu​, select ​3D Environment​. A menu is displayed.
  2. Select ​3D Display​, then select ​Avatar Deformation Map​. The deformation map is displayed in the ​3D window​​.
​2023.2 and newer​

Soft Map

The soft map differentiates between the softness level of different body parts.
To access the soft map:
  1. In the ​3D window​​, right click the avatar. A menu is displayed.
  2. Select ​Avatar Textures​. The avatar texture options are displayed.
  3. Select Soft Map​.
