From the Browzwear Cloud Library, you can download the parametric avatar Oliver in seven different sizes. You can then use these sizes to create an avatar size set.
To use this version of Oliver in different sizes and create the size set:
-
Download Oliver from the Browzwear Cloud Library. For more information, refer to Import from Cloud.
-
When the download is complete, a message is displayed asking if you want to import the avatar into VStitcher. Click Yes.
The different versions of Oliver are displayed in the Resources tabs, under 3D > Avatars.
-
Add the avatar size set. For more information, refer to Avatar Size Set.
The following table presents the body part measurements (in cm) for the seven different sizes of the Oliver avatar which you can download from the Browzwear Cloud Library. For more information, refer to Import from Cloud.
|
Body part/ Size |
EU 44 US 34 XXS |
EU 46 US 36 XS |
EU 48 US 38 S |
EU 50 US 40 M |
EU 52 US 42 L |
EU 54 US 44 XL |
EU 56 US 46 XXL |
|---|---|---|---|---|---|---|---|
|
Height |
180.25 |
180.25 |
180.25 |
180.25 |
180.25 |
180.25 |
180.25 |
|
Neck |
38.25 |
39.25 |
40.25 |
41.25 |
42.75 |
44.25 |
45.75 |
|
Shoulders |
41 |
42 |
43 |
44 |
45 |
46 |
47 |
|
Shoulder slop |
6 |
6 |
6 |
6 |
6 |
6 |
6 |
|
Nape to waist |
45.5 |
45.5 |
45.5 |
45.5 |
45.5 |
45.5 |
46 |
|
Chest |
86 |
91 |
96 |
101 |
106 |
111 |
117 |
|
Below chest |
80.5 |
85.5 |
90.5 |
95.5 |
100.5 |
105.5 |
111.5 |
|
HPS to chest |
26.3 |
26.6 |
26.9 |
27.2 |
27.5 |
27.8 |
28.4 |
|
Apex to Apex |
17.5 |
18.5 |
19.5 |
20.5 |
21.5 |
22.5 |
23.5 |
|
Wiast |
72.5 |
77.5 |
82.5 |
87.5 |
93 |
98.5 |
104.5 |
|
Hip |
85 |
90 |
95 |
100 |
105 |
110 |
115 |
|
High hip |
77 |
82 |
87 |
92 |
97 |
102 |
107.5 |
|
Arm hole |
40 |
41.5 |
43 |
44.5 |
46 |
47.5 |
49 |
|
Arm length |
63.25 |
63.5 |
63.75 |
64 |
64.25 |
64.5 |
64.75 |
|
Bicep |
30.5 |
31.5 |
32.5 |
33.5 |
34.5 |
35.5 |
37 |
|
Elbow |
26.75 |
27.5 |
28.25 |
29 |
29.75 |
30.5 |
31.5 |
|
Wrist |
17.7 |
18 |
18.3 |
18.6 |
19 |
19.5 |
20 |
|
Outsteam |
111.2 |
110.7 |
110.2 |
109.7 |
109.2 |
108.7 |
108.2 |
|
Insteam |
81.3 |
81.3 |
81.3 |
81.3 |
81.3 |
81.3 |
81.05 |
|
Thigh |
50.5 |
53 |
55.5 |
58 |
60.5 |
63 |
65.5 |
|
Knee |
34 |
35 |
36 |
37 |
38.5 |
40 |
42 |
|
Knee height |
48.5 |
48.5 |
48.5 |
48.5 |
48.5 |
48.5 |
48.5 |
|
Calf |
35.5 |
36.5 |
37.5 |
38.5 |
39.5 |
40.5 |
42.5 |
|
Ankle |
24.3 |
24.8 |
25.3 |
25.8 |
26.6 |
27.4 |
28.2 |
|
Head circumfrence |
56.5 |
57 |
57.5 |
58 |
58.5 |
59 |
59 |
For more information on adding, using, and deleting size sets, refer to Avatar Size Set.
